Riddler Diff Cover On the Way!

[LibertyTC]

Paint Job Completed!

With multiple spray masking and hand painting, the 3 coats produced this result.
41099[/ATTACH]"]

You must be registered for see images attach

Another day of dry time & it is ready for final gloss clear coats.



[moose340]

Thats soooo sweet looking! Man thats so awesome!



[Dave]

With multiple spray masking and hand painting, the 3 coats produced this result.
41101[/ATTACH]"]

You must be registered for see images attach

Another day of dry time & it is ready for final gloss clear coats.

Looks good TC.

Dave



[tommudd]

wonder if it will ever get any dirt on it :shrug:



[yellocoyote]

I would imagine it would driving up into those pretty mountains that are in his backyard.



[LibertyTC]

Ya not to worry it gets a bit dirty sometimes. I drove some dirt country roads today and then got permission from farmer to drive onto his field to get this photo today. This Is Mount Baker In Washington State. Taken from about 50 miles away. Only in winter do the skies clear, as the haze from summer heating and the pollution from the valley, causes the hazy distortions.
Mt. Baker is part of the ring of fire & stands just under 11,000 feet and for further reading:
http://en.wikipedia.org/wiki/Cascade_Range
41113[/ATTACH]"]

You must be registered for see images attach

Mt. Baker is the sleeping Giant in Washington State and remains snow covered all year.



[yellocoyote]

Nice! (cool)



[LibertyTC]

Now it gets tricky...

I knew the cover paint job was way too pretty for a 4x4 in red.
What I wanted to achieve was a spider web type effect close to emblem.
So heated the cover and warmed the clear coat, causing paint to fracture.
This is now what it looks like. Art in the oven at 170 degrees.
41151[/ATTACH]"]

You must be registered for see images attach

:smokin:



[LibertyTC]

Riddler Diff Cover Installed!

All looks good inside of Trac-Lok.
Used 2.5 quarts Lucas 85w-140 plus the 4 ounces of Limited slip additive.
Installed with Lubelocker Gasket & new SKT bolts torqued in sequence by hand at 28 Ft/lb.
41412[/ATTACH]"]

You must be registered for see images attach

I guess some black touch up paint around the new Riddler cover is needed now.

Edit: Black paint sprayed around cover and new sticker added to hatch glass.
41414[/ATTACH]"]

You must be registered for see images attach



[tjkj2002]

I rammed my front Riddler cover on some rocks last sunday and it did not even phase the cover.Though if I had used a lubelocker gasket it would have leaked on how I hit it as the whole weight of the front of my KJ was resting on the very bottom lip of the Riddler cover,four times.With the Ultra Gray RTV no leaks.



[LibertyTC]

No Skid up Front?
If you were hitting with your lift, I could not even go or think of that serious rock crawling!
Looks like you had fun though!
Even for the basic rock stuff I need some rails! (maybe next year)
and the Lubelocker is just a test right now, it may not be permanent, will keep an eye on it



[tjkj2002]

No Skid up Front?
If you were hitting with your lift, I could not even go or think of that serious rock crawling!
Looks like you had fun though!
Even for the basic rock stuff I need some rails! (maybe next year)
and the Lubelocker is just a test right now, it may not be permanent, will keep an eye on it

Remember I'm not IFS anymore.

Front D44 Riddler aftermath................

You must be registered for see images attach

My rear diff skid got a good workout to................

You must be registered for see images attach



[LibertyTC]

That's some pretty impressive metal removal, considering your clearance!
Wonder what would have happened with a stock stamped steel front D44 cover?
Probably would have peeled back like a banana!
The sound was it some bang and then a crunch when contacts made? on downward slope or what? Any video?
